The Ubiquiti Networks AM-5G17-90 AirMAX 5 GHz 2×2 MIMO Sector Antenna offers networking flexibility and convenience. Create a customized base station using an optional RocketM radio. Operating under the 5 GHz frequency, it provides a high gain of 17 dBi and delivers 2×2 MIMO performance. This antenna supports airMAX technology, utilizing Time Division Multiple Access protocol for efficient data transmission and reception at pre-designated time slots. The package includes a pole mount, RocketM bracket, and weatherproof RF jumpers for an easier base station setup.
Ubiquiti Networks AirMAX 5 GHz 2×2 MIMO Sector Antenna AM-5G17-90 – High Gain 17 dBi
$63.20
Ubiquiti Networks AM-5G17-90 AirMAX Sector Antenna for 5 GHz networks with 17 dBi gain & 2×2 MIMO technology
Free U.S. Standard Shipping
30-Day Money Back
100% Secure Payments
Top-notch support
In stock
Description
Additional information
| Weight | 3.1 lbs |
|---|---|
| Dimensions | 16.5 × 4.7 × 4.6 in |
| Frequency Range | 4.90 to 5.85 GHz |
| Gain | 16.1 to 17.1 dBi |
| Hpol Beamwidth | 72° (6 dB) |
| Vpol Beamwidth | 93° (6 dB) |
| Beamwidth | Electrical: 8° |
| Electrical Downtilt | 4° |
| VSWR (Voltage Standing Wave Ratio) | 1.5:1 |
| Wind Survivability | 125 mph |
| Wind Loading | 6 lbf @100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 22 dB Min |
| ETSI Specification | EN 302 326 DN2 |
